Description
Overview
- 13.7 cubic feet
- 240 or 208 Volts
- 80 or 90 amp breaker required
- Sectional design
- 3 Zone Bartlett Controller at NO EXTRA CHARGE
- Patented lid lifter at NO EXTRA CHARGE
- Double wall construction
Product Description
The Cone Art Kiln model 4222D is a 13.7 cubic feet oval kiln with a full 42″ width, 31″ from front to back and a 22.5″ depth. The 4222D is designed for a busy production or sculpture studio. It is a double insulated kiln with 2.5 ” of premium firebrick plus 1″ of block insulation around the walls. The floor and lid are constructed with 3″ firebrick and has an additional 1″ of block insulation. The entire kiln, including the lid, is clad in a stainless steel jacket for extra protection and durability.
The extra insulation ensures even firings, stops heat loss through the walls and lid, saves 30% in electricity costs, and lengthens element life.
There are heavy-duty Kanthal A-1 elements in the walls and floor. This kiln makes firing up to cone 10 effortless even with heavy loads.
The kiln is equipped with a Bartlett Controller with 3 Zone Control at NO EXTRA CHARGE which is mounted on an angled easy view panel.
The Cone Art Kiln model 4222D also comes with our patented LID LIFTER at NO EXTRA CHARGE.
This kiln is available with either the standard V6-CF keypad or the new Genesis touch screen. The standard model is the BX4222D. The Genesis version is GX4222D.
The 4222D has all the features and more that you need in a professional kiln.
Furniture Kit
High alumina furniture rated to cone 11.
- Three 26" x 13" x 3/4" rectangular shelves
- Six 21″ diameter half round shelves
- Nine each 1″, 2″, 4″, 6″, and 8″ posts
- Two kg kiln wash
- The posts are 1-3/4″ square
