Description
Overview
- 5.83 Cubic feet
- 23.5″ wide X 22.5″ deep
- Double wall construction
- Kanthal A-1 Elements
- Sectional Design
- 208 or 240 Volts
- 60 Amp breaker required
- New Lid lifter Design at NO EXTRA CHARGE
- CSA Approved
Description
The Cone Art Kiln model 2322D is the newest kiln in Cone Art’s line up offers all the power of a 2322D in a marginally smaller package. With a 23.5” interior diameter this kiln is suited for 21” diameter shelves, yet with the 22.5” interior height it’s just a little easier to reach the bottom. Built with 3 thermocouples and the same power as its 27” deep cousin, this model can easily fire hot, fast, and evenly. Double wall construction keeps energy efficiency high, and our standard element in the floor helps to ensure even firings every time. Just like the deeper models, this kiln easily disassembles into 3 sections for easy delivery. This is an ideal kiln for those who have a challenge reaching the bottom of standard sized kilns.
This kiln is available with either the standard V6-CF keypad or the new Genesis touch screen. The standard model is the BX2322D. The Genesis version is GX2322D.
Furniture Kit
- Three 21″ diameter full shelves
- Two 21″ diameter half shelves
- Four 1" posts
- Three each 2″, 6″, and 8" posts
- Six each 4″ posts
- All posts are 1-3/4″ square
- 2 kg kiln wash
Downloadable PDFs
